Electric Quiet Cheap Screw Air Compressor Rotorcomp Rotary Air Compressor

Products DescriptionAdvantages:1. China-Japan latest technology cooperation, high reliability.2. Oil Cooling Permanent Magnetic Motor.3. IP65 protection grade & heavy duty air filter, suitable for high dusty environment.4. IE4 Efficiency motor efficiency.5. Most energy saving mode, Only work at loading.6. Wide frequency rang

Featured Products

Products Description
Advantages:
1. China-Japan latest technology cooperation, high reliability.
2. Oil Cooling Permanent Magnetic Motor.
3. IP65 protection grade & heavy duty air filter, suitable for high dusty environment.
4. IE4 Efficiency motor efficiency.
5. Most energy saving mode, Only work at loading.
6. Wide frequency range 25%-100%.
7. Premium Magnetic material resist more than 180ºC temp.
8. Reliable PM motor supplier from Italy.
9. Direct Taper connection, no transmission power loss, easy maintenance.
10.Touch Screen PLC with preset running schedule, more intelligent control.
11. Both main motor and fan motor are inverter control, more accurate control.
12. Easy for installation and service.
13. Fantastic Energy Saving, save up to more than 30-40%.

Details Images
Electric Silent Cheap Screw Air-Compressors Rotorcomp Rotary Air Compressor


HIGH EFFICIENCY AIREND

Electric Silent Cheap Screw Air-Compressors Rotorcomp Rotary Air Compressor

High efficiency Airend profile, specially design this PM motor application, optimize the compressor efficiency. * Original world famous bearing brand from SKF or TIMKEN or FAG. * Big airend with low RPM to help get better performance, max. RPM is around 1500RPM, extend life span of airend.


HIGH QUALITY PM MOTOR

Electric Silent Cheap Screw Air-Compressors Rotorcomp Rotary Air Compressor

The motor winding take use of new technology vacuum expoxy potting process, it increase the thermal conducivity and motor insulation protection
Automatic vacuum expoxy processing enhance the motor quality
The new seal technology of winding, it is sealed with expoxy, better protection for winding.
F grade insulation grade, resist up to 180degree, integrated PTC protection.



PM MOTOR COOLING

Electric Silent Cheap Screw Air-Compressors Rotorcomp Rotary Air Compressor

Liquid Cooling, IP65 PM Motor. Indepent cooling system.


SCR heavy duty air filter

Electric Silent Cheap Screw Air-Compressors Rotorcomp Rotary Air Compressor



OVERSIZE COOLER

Electric Silent Cheap Screw Air-Compressors Rotorcomp Rotary Air Compressor

Oversize Cooler to make sure the compressor run max up to 46degree without any problem.


LATEST TOUCH SCREEN PLC

Electric Silent Cheap Screw Air-Compressors Rotorcomp Rotary Air Compressor

* 7" Inch touch screen display. * Full feature protection. * Multi intelligent control, like running schedule. * Support Modbus
RTU. * Remote monitoring is option


HIGH EFFICIENCY SEPARATION SYSTEM

Cyclone oil tank design encsure the high separation efficiency. First stage mechanical centrifugal separation. Second stage is high efficiency oil separator. 4000hours life-span of oil separator. The oil content is lower than 3PPM.


LATEST V/F Inverter

Electric Silent Cheap Screw Air-Compressors Rotorcomp Rotary Air Compressor

* Latest V/F technology Inverter. * CE/UL Certificed Inverter. * Both Motor are inverter control. * High reliable inverter brand proofed in the market. * Professional service support. * Automatic airend speed adjust to match your air demand, help good energy saving
Why Choose EPM2
Model :
Energy Saving Series (EPM2)
Type:
Oil Injected Permanent Magnetic Screw Compressor
Voltage:
380V/50HZ/3P, 220V/60HZ/3P, 400V/50HZ/3P, 415V/50HZ/3P or Customer′s Requirements
Working Pressure:
7bar/8bar/10bar
Installed Motor Power:
55~110 Kw
Color:
Blue
Driven Method:
Taper Connection Direct Driven
Air End:
High Efficiency Airend
Trademark:
SCR
Transport Package:
Standard Wooden Packing
Available Certificate:
CE, ISO, UL, ASME, GHOST
Origin:
Shanghai, China
application:
Packing,Painting,Precision Electroplating,Peparing
PERFORMANCE COMPARISON VSD
Model
Rated Pressure

(BAR)
Capacity

(m3/min)
Motor Power

(kW)
Specific Power

(kW/(m3/min))
Electric Power cost

(kW/m3)
Energy Saving %
SCR100EPM2
8
16
75
6.19
0.1031

Traditional VSD
8
13
75
6.9
0.115
11.5%
Traditional VSD
8
16
90
6.75
0.1125
9.1%
10% better performance compare with traditional compressor
PERFORMANCE COMPARISON FIXED SPEED
Model
Capacity
Motor Power
Specific Power
Electric Power cost
Loading Percentage
Acutal Electric Power cost
Energy Saving %
(m3/min)
(kW)
(kW/(m3/min))
(kW/m3)
(kW/m3)

SCR100EPM2
16
75
6.19
0.1031
0.1051


Traditional
13
75
6.9
0.115
0.1251
19.03%
19.03%
Traditional
16
90
6.75
0.1125
0.1223
16.37%
16.37%
16%-20% energy savint compare with traditional compressor
Certifications
Electric Silent Cheap Screw Air-Compressors Rotorcomp Rotary Air Compressor


Recommend Products

Electric Silent Cheap Screw Air-Compressors Rotorcomp Rotary Air Compressor


Company Profile

Shanghai Screw Compressor Co., Ltd(SCR) is a leading compressor manufacturer in Shanghai, China with rich experience. Our brand "SCR" is the No. 1 native compressor brand in China. Which is also authorized "Shanghai Famous brand", "Shanghai well-known trade mark".

As a high-tech company, SCR focuses on developing and manufacturing of screw air compressor, owning a product family mainly cover stationary, mobile, oil free and frequency compressor. SCR products passed CE, UL, CSA, ASME certification.

As top native compressor brand, the success of SCR contributes to the perfect combination of our unremitting efforts and advanced tech globally.

Quality, competitive prices, solid worldwide distribution network and service as our hallmark have enabled us to serve our customers around the world. Our products are available in 43 countires covering Europe, America, Australia, Asia, Africa, Middle-East, and in countries such as USA, Canada, U. K., Germany, Hungary, Italy, Spain, Poland, Finland, Russia, Australia, U. A. E, Saudi Arabia, Egypt, Singapore, Thailand, Vietnam, Malaysia, Indonesia, India, South Africa, Morocco, Algeria, Colombia, Mexico, Argentina, Brasil, etc. At same time we have 22 distributors in diffierent countries.
Electric Silent Cheap Screw Air-Compressors Rotorcomp Rotary Air Compressor


Exhibition
Electric Silent Cheap Screw Air-Compressors Rotorcomp Rotary Air Compressor

FAQ
1 What trade terms do we provide? What kind of settlement currency do we offer?
Trade term :CIF ,CFR ,FOB,Ex-Works As far Our business traded in Dollars ,Euros and RMB .

2 How long is our delivery?
Our standard delivery time is 30-40 days after confirmation order & receiving recipets for standard compressors, for the other non standard requirement will be discussed case by case.

3 What is the voltage of the compressor?
The available voltage include 380V/50HZ/3Phase, 400V/50HZ/3P, 415V/50HZ/3P, 220V/60HZ/3P, 380V/60HZ/3P, 440V/60HZ/3P. At the same time we provide other voltage according to customer requirement.

4 Can our compressor run in high temperature environment? What is the working temperature range for our machine?
Yes ,our machine would run in high temperature environment ,until now our products have been sold to many countries which wouldmeet high temperature in summer ,such like Iraq, Saudi Arabia, Egypt, Algeria, etc. Work temperature range :1-45 ºC(33.8ºF-113ºF)

5 What's the min. Order requirement ?
Min. Order requirement is 1PCS.
